Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production

Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production

  • Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production
  • Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production
Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production
उत्पाद विवरण:
उत्पत्ति के प्लेस: चीन
ब्रांड नाम: VEOLIA
प्रमाणन: CE
मॉडल संख्या: एमके -3miniht
दस्तावेज: Veolia EDI catalog.pdf
भुगतान & नौवहन नियमों:
न्यूनतम आदेश मात्रा: 1 पीसी
मूल्य: बातचीत योग्य
पैकेजिंग विवरण: मानक निर्यात पैकिंग
प्रसव के समय: 5- 8 काम के दिन
भुगतान शर्तें: टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता: 60000 यूनिट प्रति माह
संपर्क करें
विस्तृत उत्पाद विवरण
इस mdoel की miniht प्रवाह दर सीमा: 0.5–1.6 m3 /h (2.2–7.0 gpm) इस मॉडल का मिनीहट शिपिंग वेट: 57 किग्रा (126 पाउंड)
इस मॉडल के मिनिहेट आयाम (चौड़ाई x ऊंचाई x गहराई): 30 सेमी x 61 सेमी x 29 सेमी मिनीहट प्रतिरोधकता: ≥ 10 (फार्मास्युटिकल) या (16 मोहमी-सीएम (औद्योगिक
सोडियम: ≤ 3 पीपीबी (औद्योगिक) अधिकतम स्वच्छता तापमान: 85 (C (185ºF)
अधिकतम स्वच्छता इनलेट दबाव: 2.1 बार (30 पीएसआई) आवेदन: फार्मास्युटिकल प्यूरीफाइड वाटर

Veolia E-Cell MK-3 Mini HT EDI module for pharmaceutical ultrapure water production
Key Specifications
Flow Rate Range 0.5–1.6 m³/h (2.2–7.0 gpm)
Shipping Weight 57 kg (126 lbs)
Dimensions 30 cm x 61 cm x 29 cm
Resistivity ≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial)
Maximum Sanitization Temperature 85ºC (185ºF)
Advanced Technology Features
  • Patented HT-EDI™ technology for reagent-grade water production
  • 90% lower energy consumption compared to mixed-bed systems
  • Maintenance-free operation with intelligent control system
  • Real-time monitoring of conductivity, pH, and pressure drop
  • Patented staggered flow channel design prevents scaling
Performance Advantages

Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.

Available Configurations
  • Basic Unit - Standalone purification
  • RO-EDI Integrated - Complete purification skid
  • GMP Version - With full validation support
Quality Certifications
  • CE, RoHS, CSA and EAC marked
  • FDA-compliant materials
  • UKCA certified
  • Manufactured in ISO 9001 and ISO 14001 facility
  • Halal certified by IFANCA®
Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production 0
Technical Parameters
Parameter Value
Inlet Pressure 6.9 bar (100 psi)
Max Temperature 40°C (104°F)
Pressure Drop 1.4-2.8 bar (20-40 psi)
Recovery Rate Up to 93%
Conductivity <117 µS/cm
pH Range 4-11
Applications

Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.

Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production 1
Additional Resources

For more information about our EDI technology and application cases, visit FG Water Technologies.

About FG Water Technologies

FG Water Technologies is a high-tech entity specializing in water treatment equipment design, manufacturing, and international shipment. Our products serve various industries including pharmaceutical, food and beverage, chemical, and power.
